CPU
|
CPU Model |
Intel Xeon D-1567 |
|
CPU Quantity |
1 |
|
CPU Core |
12 |
|
CPU Architecture |
64-bit |
|
CPU Frequency |
2.1 (base) / 2.7 (turbo) GHz |
|
Hardware Encryption Engine |
 |
|
Memory
|
System Memory |
16 GB DDR4 ECC RDIMM |
|
Memory Module Pre-installed |
16 GB (16 GB x 1) |
|
Total Memory Slots |
4 |
|
Maximum Memory Capacity |
128 GB (32 GB x 4) |
|
Notes |
- Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
- Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
- For more information on memory upgrade limitations, visit here.
- For more information on the recommended memory configurations, visit here.
|
|
Storage
|
Drive Bays |
24 |
|
Maximum Drive Bays with Expansion Unit |
48 (RX1217sas x 2) / 72 (FX2421* x 2) |
|
Compatible Drive Type* (See all supported drives) |
- 2.5" SAS HDD*
- 2.5" SAS SSD*
- 2.5" SATA SSD
|
|
Hot Swappable Drive* |
|
|
Notes |
- 2.5" SAS HDD and 2.5" SAS SSD only indicate the drive types that may be compatible with Synology devices. For supported drive models, please refer to the device’s compatibility list.
- "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
|
|
External Ports
|
RJ-45 1GbE LAN Port |
4 (with Link Aggregation / Failover support) |
|
RJ-45 10GbE LAN Port |
2 (with Link Aggregation / Failover support) |
|
USB 3.2 Gen 1 Port* |
2 |
|
Expansion Port |
1 |
|
Notes |
The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. |
|
PCIe
|
PCIe Expansion |
1 x Gen3 x8 slot (x8 link) |
|
Appearance
|
Form Factor (RU) |
2U |
|
Size (Height x Width x Depth) |
88 mm x 482 mm x 724 mm |
|
Weight |
14.9 kg |
|
Rack Installation Support* |
4-post 19" rack (Synology Rail Kit - RKS-02) |
|
Notes |
The rail kit is sold separately |
|
Others
|
System Fan |
80 mm x 80 mm x 4 pcs |
|
Fan Speed Mode |
- Full-Speed Mode
- Cool Mode
- Quiet Mode
|
|
Easy Replacement System Fan |
|
|
Power Recovery |
|
|
Noise Level* |
57 dB(A) |
|
Scheduled Power On / Off |
|
|
Wake on LAN / WAN |
|
|
Power Supply Unit / Adapter |
500 W |
|
Redundant Power Supply |
|
|
AC Input Power Voltage |
100V to 240V AC |
|
Power Frequency |
50/60 Hz, Single Phase |
|
Power Consumption |
258.23 W (Access)
127.99 W (HDD Hibernation) |
|
British Thermal Unit |
881.12 BTU/hr (Access)
436.72 BTU/hr (HDD Hibernation) |
|
Notes |
- Power consumption is measured when it is fully loaded with HGST 1.8TB HUC101818CS4204 hard drive(s).
- Noise Level Testing Environment: Fully loaded with Toshiba 600GB AL14SEB060N hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
|
Temperature
|
Operating Temperature |
0°C to 35°C (32°F to 95°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
|
Certification
|
- FCC
- CE
- BSMI
- EAC
- CCC
- VCCI
- RCM
|
|
Warranty
|
5 Years |
|
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
|
Environment
|
RoHS Compliant |
|
Packaging Content
|
- Main Unit X 1
- Accessory Pack X 1
- AC Power Cord X 2
- Quick Installation Guide X 1
|
|
Optional Accessories
|
|
|
Notes |
- It is required to use D4RD-2666-16G with identical memory modules of the same capacity and frequency. For more information, visit here.
- Expansion Unit FX2421 can only be used with identical expansion units.
|
