General
|
Host Bus Interface |
PCIe 3.0 x8 |
|
Bracket Height |
Low Profile and Full Height |
|
Size (Height x Width x Depth) |
71.75 mm x 200.05 mm x 17.70 mm |
|
Operating Temperature |
0°C to 40°C (32°F to 104°F) |
|
Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
|
Relative Humidity |
5% to 95% RH |
|
Warranty |
5 Years |
|
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more) |
|
Storage
|
Storage Interface |
PCIe NVMe |
|
Supported Form Factor |
22110 / 2280 |
|
Connector Type and Quantity |
M-key, 2 Slots |
|
Network
|
IEEE Specification Compliance |
- IEEE 802.3x Flow Control
- IEEE 802.3u Fast Ethernet
- IEEE 802.3ab Gigabit Ethernet
- IEEE 802.3bz 2.5Gbps / 5Gbps Ethernet
- IEEE 802.3an 10Gbps Ethernet
|
|
Data Transfer Rates |
10 Gbps |
|
Network Operation Mode |
Full Duplex |
|
Supported Features |
- 9 KB Jumbo Frame
- TCP/UDP/IP Checksum Offloading
- Auto-negotiation between 100Mb/s, 1Gb/s, 2.5Gb/s, 5Gb/s, and 10Gb/s
- TCP Segmentation Offload (TSO)
- Large Send Offload (LSO)
- Receive Side Scaling (RSS)
- Generic Receive Offload (GRO)
- Generic Segmentation Offload (GSO)
|
|
Compatibility
|
|
Applied Models
|
NVMe SSD |
- SA series:SA6400, SA3610, SA3600, SA3410, SA3400
- 23 series:RS2423RP+, RS2423+
- 22 series:RS822RP+, RS822+, DS3622xs+, DS2422+
- 21 series:RS4021xs+, RS3621xs+, RS3621RPxs, RS2821RP+, RS2421RP+, RS2421+, RS1221RP+, RS1221+
- 20 series:RS820RP+, RS820+
- 19 series:DS2419+II, DS2419+, DS1819+
- 18 series:RS3618xs, RS2818RP+, DS3018xs, DS1618+
- 17 series:RS18017xs+, RS4017xs+, RS3617xs+, RS3617RPxs, DS3617xsII, DS3617xs
|
|
Notes |
- DSM version requirement: 6.2.3-25426 or later version
- DSM version requirement for RS18017xs+, RS4017xs+, RS3618xs, RS3617xs+, RS3617RPxs, DS3617xs and DS3617xsII: 7.0.1 or later version
|
